Toroid Ferrite Core T50-26 Iron Ring with Inner Diameter of 7.5 mm

This is a brand-new, high-quality T50-26 Toroid Ferrite Core. It is constructed from iron and is available in yellow and white colors.

Specifications

• Model: T50-26
• Material: Iron
• Color: Yellow, White
• Outer Diameter: Approximately 13mm
• Inner Diameter: Approximately 7.5mm
• Height: Approximately 5mm
• Circumference: Approximately 3.19cm
• Area: Approximately 0.112cm2
• Volume: 0.358cm3
• Inductance Coefficient (T50-26): 33.0nH/N2
• Permeability: 75μo
• Density: 7.0cm3
• Curie Temperature: 825 ℃
• Permeability Temperature Coefficient: 825 (+ ppm / ℃)
• Linear Expansion Coefficient: 12 (+ ppm / ℃)

Features

The T50-26 Toroid Ferrite Core is typically stored near signal sources. It is characterized by its isolation eddy current, low permeability, and constant magnetic properties. This product is known for its stable and reliable performance, as well as its durability. It is commonly used in power transformers, current transducers, instrument transformers, inductors, chokes, ballasts, voltage stabilizers and regulators, welding transformers, broad band transformers, filters, and more.

Package Contents

The package includes one T50-26 Toroid Ferrite Core.
